E42 PS Pump

  • Out of stock

The full chapter is not available.

However, you can choose retail parts.

E42 PS Pump

€13,441.45
  • Out of stock
Pack content
Ref Name Qty Price Number
  1 Power Steering Pump - Tarmac
904600278A
1 €1,062.00

  2 Gravel Power steering pump
904600288A
1 €1,062.00

  3 Copper seal Ø16x22x1,5
PS81614A10
1 €2.83

  4 Adaptator DASH 6 16x150 M/M
PS73500A10
1 €15.75

  5 PS pump bracket
904474008A
1 €649.26

  6 Powersteering pump pulley
0A1818158A
1 €342.00

  7 Socket Screw M8-16 12.9
PS82130A01
4 €1.50

  8 Flat washer-8x16x1
PS86057A10
3 €20.04

  9 Screw CHC M8-30 12.9
PS82079A10
3 €1.28

  10 Washer 8x18-1.5
PS86019A10
2 €1.53

  11 Screw M8X125 L35
9802558580
3 €3.03

  12 CENTERING PIN
904475948A
2 €95.40

  13 PIN SX18
3211-07
1 €2.13

  14 PS Cooler COOLER
904606558A
1 €563.89

  15 Cooler holder
ST00100002
1 €0.22

  16 Screw CHC m6x14 cl.12.9
PS82036A10
1 €0.96

  17 M6 H Nut
PS74040A10
1 €1.36

  18 Nut Dash 8
PS73682A10
2 €5.71

  19 Cooler to Tank Hose 1/2
904606528A
1 €395.41

  20 Tank to PS Pump Hose
904606548A
1 €479.74

  21 Cooler to Tank Hose 2/2
904606538A
1 €404.01

  22 Female SPH08 DASH8 JV ALU
PS73361A10
2 €587.02

  23 Male SPH08 DASH8 JV ALU
PS73358A10
2 €870.93

  24 Cooler to Tank HOSE
904605228A
1 €389.88

  25 Reservoir Bracket
401896
1 €10.89

  26 Socket Screw M6-16 12.9
PS82156A10
2 €0.69

  27 A type wave washer D6
PS86004A10
2 €2.67

  28 Nut With Washer M6X100
PS74006A10
2 €11.02

  29 Power steering TANK
904604928A
1 €792.00

  30 BRAKE FLUID RESERVOIR FILTER
4644-20
1 €5.55

  31 Tank CAP
9844684080
1 €8.61

  32 Seal for tank cap
1E4242411A
1 €7.56

  33 Oil level indicator (Alu 180°C 3/4)
90344293-A
1 €66.42

  34 Accessory belt
1606349480
1 €37.98

  35 PS Pump to Fiter Hose
904606488A
1 €280.71

  36 Filter to Steering Rack Hose
904606498A
1 €299.79

  37 Steering Rack to cooler hose 1/2
904606508A
1 €202.59

  38 PS HOSE BRACKET
904606598A
2 €8.77

  39 PS Hoses clamp
904482758A
1 €100.08

  40 O-RING A7.65 T1.78 HNBR 90SH GREEN
ST03600360
4 €2.92

  41 O-ring
219040-391
4 €3.55

  42 FILTER BOX
904605178B
1 €323.95

  43 Filter 10µM HYDAC
PS02519A10
1 €104.53

  44 VALVE SUPPORT
904605208B
1 €154.35

  45 Anti-retirn valve
ST06100002
1 €173.29

  46 Oring A39.34 T2.62 FKM 80SH
CS360040ST
1 €5.17

  47 FILTER COVER
904605188B
1 €186.75

  48 FILTER SUPPORT
904605218B
2 €87.75

  49 RACCORD PLUG SPH05 9/16-18 DASH6
ST04100037
1 €803.70

  50 RACCORD SOCKET SPH05 9/16-18 DASH6 JV
ST04100036
1 €1,057.90

€13,441.45
